LibreOffice命令
# libreoffice4.4 --helpLibreOffice 4.4.7.2 f3153a8b245191196a4b6b9abd1d0da16eead600 Usage: soffice [options] [documents...] Options:--minimized keep startup bitmap minimized.--invisible no startup screen, no default document and no UI.--norestore suppress restart/restore after fatal errors.--quickstart starts the quickstart service--nologo don't show startup screen.--nolockcheck don't check for remote instances using the installation--nodefault don't start with an empty document--headless like invisible but no userinteraction at all.--help/-h/-? show this message and exit.--version display the version information.--writer create new text document.--calc create new spreadsheet document.--draw create new drawing.--impress create new presentation.--base create new database.--math create new formula.--global create new global document.--web create new HTML document.-o open documents regardless whether they are templates or not. -n always open documents as new files (use as template).--display <display> Specify X-Display to use in Unix/X11 versions. -p <documents...> print the specified documents on the default printer.--pt <printer> <documents...> print the specified documents on the specified printer.--view <documents...> open the specified documents in viewer-(readonly-)mode.--show <presentation> open the specified presentation and start it immediately--accept=<accept-string> Specify an UNO connect-string to create an UNO acceptor through which other programs can connect to access the API--unaccept=<accept-string> Close an acceptor that was created with --accept=<accept-string> Use --unnaccept=all to close all open acceptors--infilter=<filter>[:filter_options] Force an input filter type if possible Eg. --infilter="Calc Office Open XML" --infilter="Text (encoded):UTF8,LF,,,"--convert-to output_file_extension[:output_filter_name[:output_filter_options]] [--outdir output_dir] files Batch convert files. If --outdir is not specified then current working dir is used as output_dir. Eg. --convert-to pdf *.doc --convert-to pdf:writer_pdf_Export --outdir /home/user *.doc --convert-to "html:XHTML Writer File:UTF8" *.doc --convert-to "txt:Text (encoded):UTF8" *.doc--print-to-file [-printer-name printer_name] [--outdir output_dir] files Batch print files to file. If --outdir is not specified then current working dir is used as output_dir. Eg. --print-to-file *.doc --print-to-file --printer-name nasty_lowres_printer --outdir /home/user *.doc--cat files Dump text content of the files to console Eg. --cat *.odt--pidfile file Store soffice.bin pid to file. -env:<VAR>[=<VALUE>] Set a bootstrap variable. Eg. -env:UserInstallation=file:///tmp/test to set a non-default user profile path. Remaining arguments will be treated as filenames or URLs of documents to open.
libreoffice命令行方式将word、excel、ppt转成pdf
项目需要,上传doc、excel、ppt等格式文件到服务器,用户可以在线阅读。经过讨论,决定在上传文件的同时,转换出一份pdf文件保存,用户阅读就只需要展示pdf文件即可,下载可以下载原文件。因为pdf文件需要在web页面上展示还是比较方便的,直接使用html的embed标签就能实现,也可以使用一些pdf.js的插件实现:
<!DOCTYPE HTML> <html> <body> <embed src="zpdf.pdf" width="100%" height="600"> </body> </html>
首先我们需要将doc等格式的文档转换成pdf,网上搜索一翻,实现方式也就那几种,最主流的就是通过openoffice.org或者libreoffice两种方式实现,其实libreoffice也是从openoffice.org分离出来的,功能上面应该相差不大。对于要实现格式转换,两种库都可以。
我这里直接使用libreoffice的方式。
首先安装libreoffice,我的服务器是centos,直接使用:
[root@instance-32spzihn /]# yum install libreoffice
提示是否是要安装,执行y就可以了。
一般情况下用yum安装的包都不会是最新版本的,想要安装最新版本,只能够自己下载最新的回来,手动编译安装:
libreoffice官网:http://zh-cn.libreoffice.org/
目前最新版本:LibreOffice_5.4.0_Linux_x86-64_rpm.tar.gz
[root@instance-32spzihn src]# tar -zxvf LibreOffice_5.4.0_Linux_x86-64_rpm.tar.gz [root@instance-32spzihn src]# cd LibreOffice_5.4.0.3_Linux_x86-64_rpm/RPMS [root@instance-32spzihn RPMS]# yum install *.rpm
安装完成后执行:
[root@instance-32spzihn /]# /usr/bin/libreoffice --invisible --convert-to pdf zzz.docx
如果是自行编译需要带版本号:
[root@instance-32spzihn /]# /usr/bin/libreoffice5.4 --invisible --convert-to pdf zzz.docx
具体情况可以先用 find / -name 'libreoffice*' 查找出相关的执行程序再处理。
竟然报错:
[root@instance-32spzihn /]# /usr/bin/libreoffice --invisible --convert-to pdf zzz.docx /usr/lib64/libreoffice/program/soffice.bin X11 error: Can't open display: Set DISPLAY environment variable, use -display option or check permissions of your X-Server (See "man X" resp. "man xhost" for details)
此时只需要安装另外一个库即可解决:
[root@instance-32spzihn /]# yum install libreoffice-headless
再执行转换命令,转换成功。
sz zzz.pdf,下载pdf回到本地打开发现中文乱码,这是因为缺少中文字体支付所致,所以先把 c:\Windows\Fonts文件夹复制一份到其它盘,然后打包成Fonts.zip,通过rz Fonts.zip 将压缩包传到服务器上面。
[root@instance-32spzihn /]# cd /usr/share/fonts [root@instance-32spzihn fonts]# rz [root@instance-32spzihn fonts]# unzip Fonts.zip [root@instance-32spzihn fonts]# mv Fonts win [root@instance-32spzihn fonts]# cd win [root@instance-32spzihn win]# chmod -Rf 755 * [root@instance-32spzihn win]# mkfontscale [root@instance-32spzihn win]# mkfontdir [root@instance-32spzihn win]# fc-cache –fv
若没有生效可以试下重启服务器,再重新执行转换命令就可以了。
完成对文件转换后,那接下来就要将此功能加入项目开发上面,当前需要加入到一个php项目:
$retval = 1; // exec() might be disabled $cmd = '/usr/bin/libreoffice --invisible --convert-to pdf zzz.docx'; if (function_exists('exec')){ @exec($cmd, $output, $retval); } // Did it work? if ($retval > 0){ exit('process_failed'); }
具体实现逻辑可以根据自己实际需求做更改,原理就是程序内执行shell命令处理。
进入“组件服务”->"计算机"->"我的电脑"->”DCOM配置“,找到OpenOffice。。。。开头的,右击属性,安全,把”启动和激活权限“选择自定义,然后”编辑“添加”guest“
然后、、、
function MakePropertyValue($name,$value,$osm){ $oStruct = $osm->Bridge_GetStruct("com.sun.star.beans.PropertyValue"); $oStruct->Name = $name; $oStruct->Value = $value; return $oStruct; }function word2pdf($doc_url, $output_url){ $osm = new COM("com.sun.star.ServiceManager") or die ("Please be sure that OpenOffice.org is installed.n"); $args = array(MakePropertyValue("Hidden",true,$osm)); $oDesktop = $osm->createInstance("com.sun.star.frame.Desktop"); $oWriterDoc = $oDesktop->loadComponentFromURL($doc_url,"_blank", 0, $args); $export_args = array(MakePropertyValue("FilterName","writer_pdf_Export",$osm)); $oWriterDoc->storeToURL($output_url,$export_args); $oWriterDoc->close(true); }function topdf($file1,$pdf_file){ $output_dir = "C:/AppServ/www/swust/public/uploads/pdf/"; $doc_file = "C:/AppServ/www/swust/public/uploads/".$file1; $output_file= $output_dir.$pdf_file; $doc_file = "file:///" . $doc_file; $output_file = "file:///" . $output_file; word2pdf($doc_file,$output_file);
>我会首先尝试给绝对路径命令。
>我怀疑libreoffice二进制不工作 – 你必须找到soffice二进制,看看是否工作。
>然后,你的–convert-到pdf是不够的。它需要:
--convert-to pdf:writer_pdf_Export
一定要遵循这个大小写!
>接下来,如果您的系统上已经启动并运行了一个LibreOffice GUI实例,该命令将不会工作。它是由bug known since 2011引起的。将此附加参数添加到命令中:
"-env:UserInstallation=file:///tmp/LibreOffice_Conversion_${USER}"
这将创建一个新的,单独的环境,其可以由第二个无头LO实例使用,而不干扰由相同用户启动的可能运行的第一GUI LO实例。
>另外,请确保您指定的–outdir / pdf确实存在,并且您具有写入权限。或者,使用不同的输出dir。即使它只是第一次测试和这个调试回合:
$ mkdir ${HOME}/lo_pdfs
>因此:
/path/to/soffice \ --headless \ "-env:UserInstallation=file:///tmp/LibreOffice_Conversion_${USER}" \ --convert-to pdf:writer_pdf_Export \ --outdir ${HOME}/lo_pdfs \ /path/to/test.docx
这对我来说在Mac OS X Mavericks 10.9.5与LibreOffice v4.4.3.2(使用我的特定路径的二进制soffice,这将是不同的你反正…)。
如果所有这些都不起作用:
>这可能是一个问题,具体的DOCX文件您尝试命令与…所以创建一个非常简单的DOCX文档您自己的第一。使用LibreOffice本身。写“Hello World!”在其他空页面上。将其另存为DOCX。
>再试一次。它与简单的DOCX工作吗?
>如果它再次不工作,重复步骤7,但此时保存为ODT。
>重复步骤8,但请确保此时引用ODT。
> Last:使用soffice的完整路径,soffice.bin和libreoffice,并使用-h参数运行每个:
$ /path/to/libreoffice -h$ /path/to/soffice -h$ /path/to/soffice.bin -h
>你甚至得到一个输出吗?
>对于三个二进制文件/符号链接中的哪一个?
>记录输出。
>告诉我们你的输出!
将它们与您使用的命令行进行比较:
Are there any changes in parameter names, capitalizations, number of dashes used, etc.??
为了比较,我自己的输出在这里:
$ /Applications/LibreOffice.app/Contents/MacOS/soffice -h LibreOffice 4.4.3.2 88805f81e9fe61362df02b9941de8e38a9b5fd16 Usage: soffice [options] [documents...] Options: --minimized keep startup bitmap minimized. --invisible no startup screen, no default document and no UI. --norestore suppress restart/restore after fatal errors. --quickstart starts the quickstart service --nologo don't show startup screen. --nolockcheck don't check for remote instances using the installation --nodefault don't start with an empty document --headless like invisible but no userinteraction at all. --help/-h/-? show this message and exit. --version display the version information. --writer create new text document. --calc create new spreadsheet document. --draw create new drawing. --impress create new presentation. --base create new database. --math create new formula. --global create new global document. --web create new HTML document. -o open documents regardless whether they are templates or not. -n always open documents as new files (use as template). --display <display> Specify X-Display to use in Unix/X11 versions. -p <documents...> print the specified documents on the default printer. --pt <printer> <documents...> print the specified documents on the specified printer. --view <documents...> open the specified documents in viewer-(readonly-)mode. --show <presentation> open the specified presentation and start it immediately --accept=<accept-string> Specify an UNO connect-string to create an UNO acceptor through which other programs can connect to access the API --unaccept=<accept-string> Close an acceptor that was created with --accept=<accept-string> Use --unnaccept=all to close all open acceptors --infilter=<filter>[:filter_options] Force an input filter type if possible Eg. --infilter="Calc Office Open XML" --infilter="Text (encoded):UTF8,LF,,," --convert-to output_file_extension[:output_filter_name[:output_filter_options]] [--outdir output_dir] files Batch convert files. If --outdir is not specified then current working dir is used as output_dir. Eg. --convert-to pdf *.doc --convert-to pdf:writer_pdf_Export --outdir /home/user *.doc --convert-to "html:XHTML Writer File:UTF8" *.doc --convert-to "txt:Text (encoded):UTF8" *.doc --print-to-file [-printer-name printer_name] [--outdir output_dir] files Batch print files to file. If --outdir is not specified then current working dir is used as output_dir. Eg. --print-to-file *.doc --print-to-file --printer-name nasty_lowres_printer --outdir /home/user *.doc --cat files Dump text content of the files to console Eg. --cat *.odt --pidfile file Store soffice.bin pid to file. -env:<VAR>[=<VALUE>] Set a bootstrap variable. Eg. -env:UserInstallation=file:///tmp/test to set a non-default user profile path. Remaining arguments will be treated as filenames or URLs of documents to open.
>向命令行添加一个参数,以在soffice打开DOCX文件时强制应用输入过滤器:
--infilter="Microsoft Word 2007/2010/2013 XML"
要么
--infilter="Microsoft Word 2007/2010/2013 XML" --infilter="Microsoft Word 2007-2013 XML" --infilter="Microsoft Word 2007-2013 XML Template" --infilter="Microsoft Word 95 Template" --infilter="MS Word 95 Vorlage" --infilter="Microsoft Word 97/2000/XP Template" --infilter="MS Word 97 Vorlage" --infilter="Microsoft Word 2003 XML" --infilter="MS Word 2003 XML" --infilter="Microsoft Word 2007 XML Template" --infilter="MS Word 2007 XML Template" --infilter="Microsoft Word 6.0" --infilter="MS WinWord 6.0" --infilter="Microsoft Word 95" --infilter="MS Word 95" --infilter="Microsoft Word 97/2000/XP" --infilter="MS Word 97" --infilter="Microsoft Word 2007 XML" --infilter="MS Word 2007 XML" --infilter="Microsoft WinWord 5" --infilter="MS WinWord 5"
更新
LibreOffice不仅可以在命令行上将DOCX转换为PDF:
>它可以处理任何可以打开和“读取”的输入格式:DOC,XLS,XLSX,PPT,PPTX,…
>它可以转换为任何输出格式,它可以“写”:DOC,XLS,XLSX,PPT,PPTX,…
当然,结果永远不会是完美的,有时他们甚至是你不能接受的。
回覆。输出为PDF:
要控制哪个LibreOffice组件生成PDF输出,您可以使用以下变量:
--convert-to pdf:writer_pdf_Export --convert-to pdf:calc_pdf_Export --convert-to pdf:draw_pdf_Export --convert-to pdf:impress_pdf_Export --convert-to pdf:writer_web_pdf_Export
回覆。输入不是DOCX:
要对非DOCX输入格式强制使用infilter,您可以使用(列表不完整):
--infilter="HTML Document" # for HTML input --infilter="MediaWiki" # for MediaWiki input --infilter="Text CSV" # for CSV spreadsheet input --infilter="Microsoft PowerPoint 2007/2010 XML" # for PPTX input --infilter="Microsoft PowerPoint 97/2000/XP" # for PPT input --infilter="Windows Metafile" # for WMF input --infilter="Enhanced Metafile" # for EMF input --infilter="Scalable Vector Graphics" # for SVG input --infilter="Microsoft Excel 2007/2010 XML" # for XLSX input --infilter="Microsoft Excel 97/2000/XP" # for XLS input --infilter="Microsoft Excel 95" # for some XLS input --infilter="Microsoft Excel 5.0" # for some XLS input
回覆。输出不是PDF:
要转换为特定的输出格式,您可以使用(列表不完整):
--convert-to html:HTML --convert-to html:draw_html_Export # force "Draw" to generate the HTML --convert-to mediawiki:MediaWiki_Web # generate MediaWiki output --convert-to csv:"Text - txt - csv (StarCalc)" # generate CSV spreadsheet output --convert-to pptx:"Impress MS PowerPoint 2007 XML" # generate PPTX --convert-to ppt:"MS PowerPoint 97" # generate PPT --convert-to wmf:impress_wmf_Export # force "Impress" to generate the WMF --convert-to wmf:draw_wmf_Export # force "Draw" to generate the WMF --convert-to emf:impress_emf_Export # force "Impress" to generate the EMF --convert-to emf:draw_emf_Export # force "Draw" to generate the EMF --convert-to svg:impress_svg_Export # force "Impress" to generate the SVG --convert-to svg:draw_svg_Export # force "Draw" to generate the SVG --convert-to xlsx:"Calc MS Excel 2007 XML" # generate XLSX --convert-to xls:"MS Excel 97" # generate XLS like Excel 97 --convert-to xls:"MS Excel 95" # generate XLS like Excel 95 --convert-to xls:"MS Excel 5.0/95" # generate XLS like Excel 5.0/95
